Place of Origin: | China,Jiangsu |
Marka adı: | SEAGULL |
Sertifika: | CE GS |
Model Number: | HSZ-B |
Min sipariş miktarı: | 100 adet |
---|---|
Fiyat: | Negotiable |
Packaging Details: | Higher quality double wall carton+steel pallet. |
Delivery Time: | Within 30 days after confirmation for HSZ-K type Chain Block 30T |
Supply Ability: | 10000 pieces per year |
Material: | Alloy steel | Condition: | New |
---|---|---|---|
Usage: | Construction hoist | Color: | Optional |
Warranty: | 1 year | Sling Type: | Chain |
Maximum Lifting Weight: | 30T | Maximum Lifting Height: | 18m |
Lift Speed: | Manual | Sample: | Available |
Chain Material: | G80 oil black or Zn-plating | Hook Material: | Forged&heat treatment |
Quality Test: | 100% 1.5times tested one by one before packages | ||
Vurgulamak: | hand chain hoist,chain block hoist |
1 T / 1 TON / 1 TONNE Manual Chain Block , Chain Hoist , Hoist Chain with Export Standard
features:
1) Capacity from 0.5T to 30T
2) Have certificate of CE
3) Got certificate of ISO9001
4) Automatic double-pawl braking system.
5) Asbests-free brake discs.
6) Drop forged hooks and hook holders to ensure superior quallity and safety
7) More thickness of sheet cover,gear cover and side plates for good quality.
8) The static test is 4 times of capacity,and running test is 1.5 times of capacity one by one
Model | HSZ-0.5B | HSZ-1B | HSZ-1.5B | HSZ-2B | HSZ-3B | HSZ-5B | HSZ-10B | HSZ-15B | HSZ-20B | HSZ-30B |
Rated load(T) | 0.5 | 1 | 1.5 | 2 | 3 | 5 | 10 | 15 | 20 | 30 |
Standard lift(m) | 2.5 | 2.5 | 2.5 | 2.5 | 3 | 5 | 3 | 3 | 3 | 3 |
Test load(T) | 0.75 | 1.5 | 2.25 | 3 | 4.5 | 7.5 | 12.5 | 18.75 | 25 | 37.5 |
Efforts required at capacity(N) |
262 | 324 | 395 | 330 | 402 | 430 | 438 | 447 | 438 | 442 |
Diameter at load chain(mm) |
5 | 6 | 7.1 | 6 | 7.1 | 10 | 10 | 10 | 10 | 10 |
NO. of load chains | 1 | 1 | 1 | 2 | 2 | 2 | 4 | 6 | 8 | 10 |
Dimensions(mm) A | 127 | 156 | 180 | 156 | 180 | 230 | 410 | 410 | 645 | 710 |
B | 115 | 131 | 142 | 131 | 124 | 171 | 171 | 204 | 215 | 398 |
C | 288 | 334 | 415 | 459 | 536 | 660 | 738 | 1028 | 1002 | 1050 |
Net weight(kg) | 7 | 10.5 | 15.5 | 16 | 23 | 39 | 69 | 95 | 155 | 237 |
Extra weight per meter of lift(kg) | 1.5 | 1.8 | 2 | 2.7 | 3.2 | 5.3 | 9.8 | 14.2 | 19.6 | 23.9 |
